100 hours

Course Features

  • Course Duration100 hours
  • GenderMale & Female
  • Fee for Workers5,000

Culvert Design


100 hours

For Workers



This Course will Explain and trained you that to create sub drawings and develop the culvert model from exist culvert model &standard drawings (MOT Saudi Arabia, IRC India) Based on the road design documents, the culvert length to be calculated from that the height fill will be calculated. The reinforcement will be calculated based on the culvert standard drawings. Box Culvert, Pipe culvert is the type of culvert. The calculation of structural excavation concrete Quantity, Reinforcement Quantity also to be trained in this training.

Technical Studies

  • Culvert-Functions & Standards
  • Types of Culverts
  • Design Criteria's
  • Construction Standards & Methods
  • Quantities of Culverts

Work Practice

  • Culvert Design-Normal
  • Culvert Design-Skew
  • Preparation of Drawings
  • Quantity Calculation-Steel
  • Quantity Calculation-Other Items

Software Supports

Auto CAD
MS Excel
